Siemens 1PH8103-3.M0.-...1
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | 1PH8 for SINAMICS S120 for production machines |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
| Weight | 51 kg |
Shipping & availability
When can 1PH8103-3.M0.-...1 be shipped?
1PH8103-3.M0.-...1 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 1PH8103-3.M0.-...1 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 1PH8103-3.M0.-...1 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 1PH8103-3.M0.-...1, subject to availability and destination.
SIMOTICS M compact asynchronous motor 3000 r/min 8.4 kW 27 Nm 25.7 A 297 V 3300 r/min 9.3 kW 27 Nm 25.7 A 326 V 3600 r/min 10 kW 27 Nm 25.4 A 355 V 3900 r/min 10.8 kW 26 Nm 25 A 383 V forced ventilation; direction of air flow DE--> NDE; IP55 degree of protection
