APC Smart-UPS 750VA 120V SHIPBOARD
MPN: SMT750X93 · Brand: Schneider Electric
Price on request
Request a Quote
12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
Quick facts
| Availability | Confirmed on request |
| Category | APC Smart-UPS |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
| Weight | 12.5 kg |
Shipping & availability
When can SMT750X93 be shipped?
SMT750X93 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up SMT750X93 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for SMT750X93 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for SMT750X93, subject to availability and destination.
Specifications
Specifications
| Lead time | Usually in Stock |
| Main Input Voltage | 120 V AC 1 phase |
| Input Connection Type | NEMA 5-15P |
| Input voltage limits | 82...144 V 120 V |
| Network frequency | 50/60 Hz +/- 3 Hz |
| Output voltage | 120 V AC 1 phase |
| Rated power in W | 500 W |
| rated power in VA | 750 VA |
| Output connection type | 6 NEMA 5-15R |
| Harmonic distortion | Less than 5 % |
| Maximum configurable power in VA | 750 VA |
| Maximum configurable power in W | 500 W |
| Transfer time | 6 ms typical : 10 ms maximum |
| UPS type | Line interactive |
| Wave type | Sine wave |
| Full load runtime | 00:05:00 |
| Half load runtime | 00:15:00 |
| Output frequency | 50/60 Hz +/- 3 Hz for 60 Hz nominal sync to mains |
| Battery type | Lead-acid battery |
| Control panel | LED status display with load and battery bar-graphs and on line : on battery : replace battery : and overload indicators |
| Free slots | 0 |
| UPS connectivity | Serial port, USB port, Available expansion slot |
| Surge energy rate | 593 J |
| Noise suppression | Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449 |
| Number of cables | 1 |
| Height | 161 mm |
| Width | 138 mm |
| Depth | 369 mm |
| Net weight | 12.5 kg |
| Mounting location | Front |
| Mounting preference | No preference |
| Mounting mode | Tower |
| Two post mountable | 0 |
| USB compatible | Yes |
| Provided equipment | User manual |
| Number of power module | 0 |
| Additional specification | TAA Compliant |
| Redundant | No |
| Product or component type | Uninterruptible power supply (UPS) |
| Product certifications | CSA C22.2 No 107.1 |
| Marking | UL |
| Ambient air temperature for operation | 0…40 °C |
| Ambient air temperature for storage | -20…55 °C |
| Storage altitude | 0…15000 m |
| Relative humidity | 0…95 % |
| Storage Relative Humidity | 0…95 % |
| Acoustic level | 41 dBA |
| Heat dissipation | 90 Btu/h |
| Operating altitude | 0...3000 m |
| Efficiency | View Efficiency Graph |
| Extended runtime | 0 |
| Number of battery filled slots | 0 |
| Number of battery free slots | 0 |
| Battery recharge time | 3 h |
| Number of battery replacement quantity | 1 |
| Battery life | 3…5 year(s) |
| Battery charger power | 15 W rated |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 30.1 cm |
| Package 1 Width | 49.9 cm |
| Package 1 Length | 27.8 cm |
| Package 1 Weight | 14.02 kg |
| Warranty (in months) | 36 UPS|24 Battery |
