SOCKET-PERM, 1S/10, AN

Name: SOCKET-PERM, 1S/10, AN
Brand: Danfoss (Drives)
SKU: LA7304060-10

MPN: LA7304060-10 · Brand: Danfoss (Drives)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Marine and military
Lifecycle	active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can LA7304060-10 be shipped?

LA7304060-10 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up LA7304060-10 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for LA7304060-10 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for LA7304060-10, subject to availability and destination.

Danfoss SOCKET-PERM, 1S/10, AN, manufacturer part number LA7304060-10. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A dimension IN	1.437
A dimension MM	36.500
Angle shape	Straight
Brand	Aeroquip by Danfoss
Compatible hose ID IN	0.620
Compatible hose ID MM	15.875
Construction Style	Crimp
End size 1	-10
Finish plating	Passivate
Hose size	-10
Inside diameter IN	0.807
Inside diameter MM	20.500
Product height in	1.190
Product height mm	30.226
Product length in	1.440
Product length mm	36.576
Product material	304 Stainless steel
Product width in	1.190
Product width mm	30.226 mm
Thread sealant	No
Working temperature max C	100
Working temperature max F	212
Working temperature min C	-40
Working temperature min F	-40
