3.00 CID SERVO, ACGRAGB00B31TTDMR0CAN0BBS7D
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Mobile closed-circuit piston pumps |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can 72400-SGG-04 be shipped?
72400-SGG-04 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 72400-SGG-04 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 72400-SGG-04 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 72400-SGG-04, subject to availability and destination.
Danfoss 3.00 CID SERVO, ACGRAGB00B31TTDMR0CAN0BBS7D, manufacturer part number 72400-SGG-04. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| Additional functions | Bypass valve with cross hole |
| Aux mounting features rear | [2-BOLT B] SAE flange series 101-2 |
| Aux port size and location | .750-16 UNF-2B SAE o-ring port - right (C2) side(housing) |
| Brand | Danfoss |
| Charge pump | No charge pump |
| CODE TITLE | 49.2 cm3/r [3.00 in3/r] servo controlled variabledisplacement pump |
| Control assembly | Manual control (24T 80/160P), wide band neutral, neutral lockout switch with integral weatherpack connector |
| Control servo orf S1 and S2 | Diameter 0.71 [.028] |
| Control supply orifice P | Diameter 0.91 [.036] |
| CPRV setting and routing | No charge pump |
| Design code | D |
| Destroke valve | Not required |
| Drain port size and location | Thru drain into rear auxiliary flange (D3) |
| Flow rate gpm | 46.8 |
| Flow rate lpm | 177.0 |
| Identification | Toro (customer part number stamped on unit) |
| Input shaft | 15 tooth 16/32 external, diameter 24.98 [.984], shaft extension 46 [1.81] |
| Input shaft rotation | Right hand rotation (ccw) |
| Main port size and location | 1.3125-12 UN-2B SAE o-ring port (A & B) - right side |
| Maximum output speed | 3600 |
| Maximum temperature C | 107.00 |
| Maximum temperature F | 225.00 |
| Model Code 1 | ACGRAGB00B31TTDMR0CAN0BBS7D |
| Mounting Flange | 2-bolt-B |
| Output shaft | 13 tooth 16/32 external, diameter 21.81 [.858] accepts shaft extension 17.8 [.70] max (for a unit without a charge pump) |
| Output torque lbf-in2 | 2387.3 |
| Output torque Nm | 269.7 |
| Paint | Black per spec 209-13B |
| Product height in | 10.040 |
| Product height mm | 255.016 |
| Product length in | 11.240 |
| Product length mm | 285.496 |
| Product width in | 8.530 |
| Relief vlv set for main port A | 344.7 bar [5000 lbf/in2] |
| Relief vlv set for main port B | 344.7 bar [5000 lbf/in2] |
| Special control options | Control lever with mounting hole diameter 10.31[.406], located 31.8 [1.25] from shaft centerline |
| Special features | Left hand neutral adjustment; polyacrylate drive shaft seal |
| Working pressure bar | 345 |
| Working pressure psi | 5000 |
