Adapter Str 24M SAE37 X 32M ORB

Name: Adapter Str 24M SAE37 X 32M ORB
Brand: Danfoss (Drives)
SKU: 202702-24-32S

MPN: 202702-24-32S · Brand: Danfoss (Drives)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Adapters and swivel joints
Lifecycle	active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can 202702-24-32S be shipped?

202702-24-32S is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 202702-24-32S in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 202702-24-32S and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 202702-24-32S, subject to availability and destination.

Danfoss Adapter Str 24M SAE37 X 32M ORB, manufacturer part number 202702-24-32S. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146171856
Brand	Danfoss
End Type 1	Male ORB ISO 11926-3
End Type 2	Male 37 degree
Finish plating	Dura-Kote
Hex size 1 IN	2.625
Hex size 1 MM	66.700
Item type	Adapter-straight
Product material	Carbon steel
Thread sealant	No
Thread size 1	2 1/2-12 UN
Thread size 2	1 7/8-12 UN
Tube outside diameter 1 IN	1.500
Tube outside diameter 1 MM	38.1
Tube outside diameter 2 IN	1.310
Tube outside diameter 2 MM	33.3
Working pressure bar	78.0
Working pressure psi	1125
Working temp max C	121
Working temp max F	250
Working temp min C	-40
Working temp min F	-40
