116-43206-46 ELBOW ASSY

Name: 116-43206-46 ELBOW ASSY
Brand: Danfoss (Drives)
SKU: 1469X6X2Z

MPN: 1469X6X2Z · Brand: Danfoss (Drives)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Adapters and swivel joints
Lifecycle	active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can 1469X6X2Z be shipped?

1469X6X2Z is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 1469X6X2Z in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 1469X6X2Z and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 1469X6X2Z, subject to availability and destination.

Danfoss 116-43206-46 ELBOW ASSY, manufacturer part number 1469X6X2Z. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	725975744246
Angle shape	90 Degree
Brand	Danfoss
Drop dimension IN	0.760
Drop dimension MM	19.30
End Type 1	Male pipe (NPTF)
End Type 2	Line/hose/tube
Hex size 1 IN	0.570
Hex size 1 MM	14.500
Hex size 2 IN	0.630
Hex size 2 MM	16.000
Item type	Adapter-elbow
Product material	Brass
Thread sealant	No
Tube outside diameter 1 IN	0.180
Tube outside diameter 1 MM	4.6
Tube outside diameter 2 IN	0.390
Tube outside diameter 2 MM	9.9
Working pressure bar	10.0
Working pressure psi	150
Working temp max C	93
Working temp max F	200
Working temp min C	-40
Working temp min F	-40
