PVM141ER14JS02AAB2311000 FA0A, PVM141ER14JS02AAB2311000 FA0A
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Medium-duty open-circuit piston pumps |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can 123AL00499A be shipped?
123AL00499A is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 123AL00499A in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 123AL00499A and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 123AL00499A, subject to availability and destination.
Danfoss PVM141ER14JS02AAB2311000 FA0A, PVM141ER14JS02AAB2311000 FA0A, manufacturer part number 123AL00499A. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| PRODUCT | VAR DISP OCP PVM PUMP |
| DISPLACEMENT | 141.0 CM3/R [8.60 IN3/R] (230 BAR MAX) |
| Valve plate | INDUSTRIAL (1800 r/min MAX) |
| Input rotation | CLOCKWISE (RIGHTHAND) |
| INPUT SHAFT | SAE J744-44-4 SAE D 13T SPLINE (MODEL 131) |
| Mounting Flange | SAE J744-152-4 (D 4-BOLT) (MODEL 131) |
| MAIN PORT LOCATION | SIDE |
| PORT OPTIONS | SAE J518 FLANGE PORTS SAE AUXILIARY PORTS |
| PUMP SPECIAL FEATURES | ADJUSTABLE MAX DISPLACEMENT STOP(CONTAINS SINGLE SHAFT SEAL) |
| CONTROL | PRESSURE AND FLOW COMPENSATOR WITH BLEED DOWN ORIFICE |
| PRESSURE COMP SET | 227-234 BAR [3277-3393 LBF/IN2] |
| FLOW COMP UNLD VLV RPC SET | 10-12 BAR [145-174 LBF/IN2] |
| UNLD VLV TQ CONTROL SET | NONE |
| COMP SPECIAL FEATURES | NONE |
| Auxiliary mounting | SAE C-C 2-/4-BOLT 17T SPLINE MODELS 074 098 AND 131 |
| Paint | BLACK [DEFAULT] |
| Customer identification | NONE |
| DESIGN CODE | A |
| Brand | Vickers by Danfoss |
| CODE TITLE | VICKERS VARIABLE DISPLACEMENT OPEN CIRCUIT PISTON PUMPS |
| IPM FRAME SIZE | PVM Code A 141cc Pump |
| Model Code 1 | PVM141ER14JS02AAB2311000 FA0A |
