F3-DGMPC-H8-ABK-BAK-10, F3DGMPCH8ABKBAK10
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Industrial valves |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can 02-413058 be shipped?
02-413058 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 02-413058 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 02-413058 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 02-413058, subject to availability and destination.
Danfoss F3-DGMPC-H8-ABK-BAK-10, F3DGMPCH8ABKBAK10, manufacturer part number 02-413058. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| Actuation Type | Pressure operated |
| Brand | Vickers by Danfoss |
| Cracking pressure 1 bar | 3.00 |
| Cracking pressure 1 psi | 44 |
| Cracking pressure 2 bar | 3.00 |
| Cracking pressure 2 psi | 44 |
| Design Series | 10 Series |
| Flow rate upto LPM | 450 |
| Flow rate upto USGPM | 119.0 |
| Fluid Cleanliness | 19/17/14 micron |
| Fluid compatibility | Petroleum oils |
| Function | A piloted from B |
| Function dual | B piloted from A |
| Interface | ISO4401-08 |
| Maximum pressure upto bar | 315 |
| Maximum pressure upto psi | 4500 |
| Model Code 1 | F3DGMPCH8ABKBAK10 |
| Performance | Standard |
| Product height in | 3.930 |
| Product height mm | 99.822 |
| Product length in | 11.810 |
| Product length mm | 299.974 |
| Product width in | 4.600 |
| Product width mm | 116.84 |
| Seal type | Viton |
| Special features | None |
| Valve Mount Type | Subplate/manifold mounted |
| Valve type | PO check valve |
| Working temp max C | 80 |
| Working temp max F | 176 |
| Working temp min C | -20 |
| Working temp min F | -4 |
