PVQ32-B2R-SE3S-21-CM7-12, PVQ32-B2R-SE3S-21-CM7-12
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Medium-duty open-circuit piston pumps |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can 02-341689 be shipped?
02-341689 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 02-341689 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 02-341689 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 02-341689, subject to availability and destination.
Danfoss PVQ32-B2R-SE3S-21-CM7-12, PVQ32-B2R-SE3S-21-CM7-12, manufacturer part number 02-341689. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| Series | INLINE PISTON PUMP WITH VARIABLE VOLUME, QUIET SERIES |
| DISPLACEMENT | 32,9 CC/REV (2.01 cir), 140 BAR (2000 PSI) |
| Mounting Flange | SAE "B" 2 BOLT |
| ROTATION (VIEWED FROM S END) | RIGHT HAND (CW) |
| THRU-DRIVE WITHOUT COUPLING | NO THRU-DRIVE |
| PORT TYPE AND LOCATION | SAE O-RING REAR PORT, 1.625” INLET AND OUTLET (STANDARD) |
| INPUT SHAFT | SPLINED SAE “B” MODIFIED, 13T 16/32 DP MAJOR DIA. FIT |
| SEALS | BUNA N, STANDARD |
| PUMP DESIGN NUMBER | 21-DESIGN NUMBER |
| CONTROL_TYPE | LOW PRESSURE COMPENSATOR, INDICATING FACTORY SETTING OF 70 BAR (1000 PSI); RANGE IS 02-10 IN TENS OF BAR (350-2000 PSI). |
| CONTROL OPTION | WITHOUT ADJUSTABLE MAXIMUM DISPLACEMENT STOP (STANDARD) |
| CONTROL DESIGN | C14, C21, CM7, C**D AND CM**D |
| SPECIAL PUMP OPTION SUFFIXES | NO SPECIAL PUMP SUFFIXES |
| IPM FRAME SIZE | PVQ 32cc Pump |
| Model Code 1 | PVQ32-B2R-SE3S-21-CM7-12 |
