PVM057ER09ES02AAA28000000A0A Nrnew PN, PVM057ER09ES02AAA28000000A0A
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Medium-duty open-circuit piston pumps |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can 02-335496 be shipped?
02-335496 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 02-335496 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 02-335496 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 02-335496, subject to availability and destination.
Danfoss PVM057ER09ES02AAA28000000A0A Nrnew PN, PVM057ER09ES02AAA28000000A0A, manufacturer part number 02-335496. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| PRODUCT | VAR DISP OCP PVM PUMP |
| DISPLACEMENT | 57.4 cm3/r [3.50 in3/r] (280 bar MAX) |
| Valve plate | INDUSTRIAL (1800 r/min MAX) |
| Input rotation | CLOCKWISE (RIGHTHAND) |
| INPUT SHAFT | SAE J744-32-1 SAE C STRAIGHT KEYED (MODEL 057 074 098 AND 131) |
| Mounting Flange | SAE J744-127-2 (C 2-BOLT) (MODEL 057) |
| MAIN PORT LOCATION | SIDE |
| PORT OPTIONS | SAE J518 FLANGE PORTS SAE AUXILIARY PORTS |
| PUMP SPECIAL FEATURES | ADJUSTABLE MAX DISPLACEMENT STOP(CONTAINS SINGLE SHAFT SEAL) |
| CONTROL | PRESSURE COMPENSATOR |
| PRESSURE COMP SET | 276-284 BAR [4002-4118 LBF/IN2] |
| FLOW COMP UNLD VLV RPC SET | NONE |
| UNLD VLV TQ CONTROL SET | NONE |
| COMP SPECIAL FEATURES | NONE |
| Auxiliary mounting | AUXILIARY MOUNT COVER PLATE |
| Paint | BLACK [DEFAULT] |
| Customer identification | NONE |
| DESIGN CODE | A |
| Brand | Vickers by Danfoss |
| CODE TITLE | VICKERS VARIABLE DISPLACEMENT OPEN CIRCUIT PISTON PUMPS |
| IPM FRAME SIZE | PVM Code A 57cc Pump |
| Model Code 1 | PVM057ER09ES02AAA28000000A0A |
