B&R 5MMSSD.0512-00 – Replacement for the SSD drive 5AC901.CSSD-06

Name: B&R 5MMSSD.0512-00 – Replacement for the SSD drive 5AC901.CSSD-06
Brand: B&R
SKU: 5MMSSD.0512-00

MPN: 5MMSSD.0512-00 · Brand: B&R

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Drives
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)
Weight	0.9 kg

Shipping & availability

When can 5MMSSD.0512-00 be shipped?

5MMSSD.0512-00 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 5MMSSD.0512-00 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 5MMSSD.0512-00 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 5MMSSD.0512-00, subject to availability and destination.

• Replacement for the SSD drive 5AC901.CSSD-06

This 512 GB solid-state drive (SSD) drive can be used as a replacement part or accessory. The SSD is based on Multi Level Cell (MLC) technology.

Specifications

General information

Certifications – CE	Yes
Certifications – UKCA	Yes
Certifications – CRA (Cyber Resilience Act)	In preparation
Certifications – UL	cULus E115267; Industrial control equipment
Certifications – HazLoc	cULus HazLoc E180196; Industrial control equipment; for hazardous locations; Class I, Division 2, Groups ABCD " data-placement="top" data-html="true" data-container="body" data-content="Yes, but applies only if all components installed in the complete system have this certification and the complete system bears the corresponding mark.">

Solid-state drive

IOPS " data-placement="top" data-html="true" data-container="body" data-content="IOPS: Random read and write input/output operations per second"> – 4k read	Max. 75,000 (random)
IOPS " data-placement="top" data-html="true" data-container="body" data-content="IOPS: Random read and write input/output operations per second"> – 4k write	Max. 76,000 (random)
Capacity	512 GB
Data reliability	Max. 1 unrecoverable error per 10 15 bits read
MTBF	Min. 3,000,000 h
S.M.A.R.T. support	Yes
Interface	SATA
Servicing	None
Continuous reading	Max. 520 MB/s
Continuous writing	Max. 450 MB/s

Endurance

Data volume – Theoretical	1536 TBW " data-placement="top" data-html="true" data-container="body" data-content="TBW = Terabytes written">
Data volume – Client workload	600 TBW " data-placement="top" data-html="true" data-container="body" data-content="Client workload per JEDEC JESD219 standard.">
MLC flash memory	Yes
Compatibility	SATA 3.1 compliant; ACS-2; SSD Enhanced SMART ATA feature set; Native Command Queuing (NCQ)
Storage health data support	Yes, AR 4.90 and later

Operating conditions

Pollution degree per EN 61131-2

Pollution degree 2

Ambient conditions

Temperature – Operation	-40 to 85°C
Temperature – Storage	-55 to 95°C
Temperature – Transport	-55 to 95°C
Relative humidity – Operation	10 to 95%, non-condensing
Relative humidity – Storage	10 to 95%, non-condensing
Relative humidity – Transport	10 to 95%, non-condensing
Vibration – Operation	7 to 2000 Hz: 20 g
Vibration – Storage	7 to 2000 Hz: 20 g
Vibration – Transport	7 to 2000 Hz: 20 g
Shock – Operation	1500 g, 0.5 ms
Shock – Storage	1500 g, 0.5 ms
Shock – Transport	1500 g, 0.5 ms

Mechanical properties

Dimensions – Width	7 mm
Dimensions – Height	69 mm
Dimensions – Depth	100 mm
Weight	Approx. 90 g

Vendor information

Manufacturer	Innodisk
Manufacturer's product ID	2.5" SATA SSD 3MV2-P 512 GB

Downloads & documentation

Official documents from B&R, downloaded directly from the manufacturer.

Data sheets & manuals

Aggregate data sheet 5AC901.CSSD-0x	PDF · 352 KB · 1.16 (11/23/2020) - EN
Aggregate data sheet 5MMSSD.xxxx-0x	PDF · 309 KB · 1.01 (11/23/2020) - EN
Automation PC 910 Device number key	PDF · 627 KB · 9.00 (11/18/2022)
Panel PC 900 (Skylake) user's manual	PDF · 73 MB · 1.10 (08/22/2022) - EN
