BALL RUNNER BLOCK RESIST CR KWD-045-SLS-C0-H-1

The ball runner block is highly precise and corrosion-resistant thanks to its Resist CR coating. Additionally, it is characterized by the following product features:<br>Size 45<br>Format SLS: Width = slimline, length = long, height = standard<br>Runner block body made of unalloyed steel CS, matte-silver, hard chrome plated<br>Preload class C0: Preload-free<br>Accuracy class H: High<br>Without ball chain<br>With initial lubrication and preservation<br>Roller bearing grease Dynalub 510<br>Without attachment element, left (front reference edge)<br>Without attachment element, right (front reference edge)<br>Straight lube connection loosely attached.<br>Runner block body in standard version<br>Overall length of the runner block = 174.1 mm<br>Interchangeability: The runner block and the guide rails can be combined with each other with every accuracy. Area of application: For restricted space in the transverse direction Ball runner block body or ball guide rail made of steel with corrosion resistant coating, matte-silver finish, hard chrome plated Significantly reduced frictional oscillations and low friction force level, particularly under external load Long-term lubrication is possible over several years Patented entry zone increases the travel accuracy up to a factor of six Attachments on the ball runner block can be mounted from above Can be used on all SNS/SNO ball guide rails Excellent dynamic characteristics End-face fastening thread for all attachments The same high load ratings in all four main directions of loading Different preload classes Ball runner block pre-lubricated at the factory

Specifications
