BELT SECTION BS 2/R-H

Name: BELT SECTION BS 2/R-H
Brand: Bosch Rexroth
SKU: 3842998939

MPN: 3842998939 · Brand: Bosch Rexroth

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Belt section accumulation roller chain
Lifecycle	active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can 3842998939 be shipped?

3842998939 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 3842998939 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 3842998939 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 3842998939, subject to availability and destination.

The belt section is a ready-to-use conveyor section with built-in drive for the transportation of workpiece pallets in the longitudinal direction or for the transverse conveying of the workpiece pallet between parallel conveyor sections in conjunction with two HQ 2 lift transverse units. Sturdy design for especially heavy-duty systems Reversible operation possible for l ≤ 2000 mm and accumulation roller chains without small parts protection Chain tensioner for reversible operation is mounted on the return unit at RV = 1 Profile width: 50 mm Special models on request Positioning of WTs in the area of the drive heads/return heads is not permitted. Low-maintenance version available Notice: The low-maintenance version of the accumulation roller chain allows it to be used without additional lubrication for higher requirements in clean environments. In addition, less installation and maintenance effort will be necessary. The service life can vary depending on the application compared to the standard chain.

Specifications

Condition on delivery	Assembled
ESD	Yes
Length max [l max] [mm]	6000
Length min [L min] [mm]	650
Track width in direction of transport [b max] [mm]	1200
Track width in direction of transport [b min] [mm]	400
Section load in accumulation operation [kg]	1200
Nominal speed [vN]	0 m/min ohne Motor und ohne Getriebe; 12 m/min; 15 m/min; 18 m/min nicht möglich bei f = 60 Hz; 6 m/min; 9 m/min
Material information	Chain: PA or steel accumulation rollers; Glide profile: Steel; corrosion-resistant; Section profile: Aluminum, natural; anodized; Small parts protection: PA
Conveyor medium	Accumulation roller chain (suitable for use in an EPA)
Recommended accessories	Connection kits; Decentralized automatic lubrication unit LU 2, or central automatic lubrication unit LU 2/P; Leg sets ST 2/...
Weight [kg]	0
