Power cable, PUR, drag-chain suitable, 5 x 2.5 mm²
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Power cables |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can ZK2051-5114-0xxx be shipped?
ZK2051-5114-0xxx is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up ZK2051-5114-0xxx in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for ZK2051-5114-0xxx and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for ZK2051-5114-0xxx, subject to availability and destination.
M12, plug, straight, male + female (PE inverse), 5-pin (4+FE), L-coded – 7/8"-16 UN, socket, angled, female, 5-pin
Specifications
Specifications
| Shielding | no |
| Installation size | 7/8"-16 UN |
| Connector type | socket |
| Contact type | female |
| Number of positions (face) | 5-pin |
| Coding | A‑coded |
| Rated current | 12 A at 40°C (according to IEC 60512-3), 10 A (according to UL2238) |
| Rated voltage | 300 V (according to IEC 60664-1) |
| Recommended torque, nut | 0.6 Nm |
| Mating cycles | ≥ 100 (according to IEC 60512-9a) |
| Cross-section | 5 x 2.5 mm² (approx. AWG14) |
| Use | drag-chain suitable |
| Material jacket | PUR (polyurethane) |
| Outer cable diameter | 9.9 mm ± 0.2 mm (0.3897" ± 0.0079") |
| Min. bending radius, moved | 10 x outer cable diameter |
| Max. number of cycles | 4 million |
| Jacket color | black |
