Servomotor with anodized housing 3.22 Nm (M0), R3 (89 mm)
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | AM8733 |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can AM8733-wFyz be shipped?
AM8733-wFyz is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up AM8733-wFyz in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for AM8733-wFyz and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for AM8733-wFyz, subject to availability and destination.
The servomotor AM8733 with anodized housing is designed for applications in food, pharmaceutical and chemical industries. It is suitable for drive solutions with highest demands on dynamics and performance in the 100…480 V AC voltage range. The motor is
Specifications
Specifications
| Motor type | permanent magnet-excited three-phase synchronous motor |
| Nominal voltage | 100…480 V AC |
| Standstill torque | 3.22 Nm |
| Rated torque | 2.70 Nm |
| Peak torque | 17.71 Nm |
| Rated speed | 6000 min-1 |
| Rated power | 1.70 kW |
| Standstill current | 4.10 A |
| Peak current | 24.6 A |
| Torque constant | 0.78 Nm/A |
| Rotor moment of inertia | 1.23 kgcm² |
| Motor feedback | resolver, single-turn absolute encoder OCT, 24 bit, SIL 2-capable, single-turn or multi-turn absolute encoder, electronic nameplate OCT, 24 bit, SIL 2-capable, single-turn or multi-turn absolute encoder, electronic nameplate, B/SSD |
| Cooling | convection |
| Connection technology | M23 speedtec® socket or direct connection for AX5000/AX8000 |
| Ambient temperature (operation) | 5…40°C |
| Approvals/markings | CE, cURus in preparation |
| Protection rating | IP69K not including shaft feedthrough |
| Design form | flange-mounted according to IM B5, IM V1, IM V3 |
| Material | aluminum |
| Coating/surface | anodized |
| a | 60 j6 |
| b | 14 k6 |
| d | 30 mm |
| l | 75 mm |
| r | 89 mm |
| k (without brake) | 186 mm |
| k (with brake) | 233 mm |
