ABB D5150R-BV – 50HP,1150RPM,DC,2514ATZ,DPG-FV,
MPN: D5150R-BV · Brand: ABB
Price on request
Request a Quote
12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
Quick facts
| Availability | Confirmed on request |
| Lifecycle | Active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can D5150R-BV be shipped?
D5150R-BV is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up D5150R-BV in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for D5150R-BV and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for D5150R-BV, subject to availability and destination.
50HP,1150RPM,DC,2514ATZ,DPG-FV,
Specifications
Additional Information
| ABB Type Designation | 50HP,1150RPM,DC,2514ATZ,DPG-FV, |
| Ambient Temperature | 40 °C |
| Armature Current | 87 A A |
| Armature Voltage | 500 V V |
| Base Speed | 1150 r/min |
| Bearing | 65BC03J30X |
| Bearing NDE | 50BC02J30X |
| Brake Present | No |
| Brand / Label | Baldor-Reliance |
| Catalog Number | D5150R-BV |
| Certification Agency | CCSA US |
| Country or Territory of Origin | United States |
| Customs Tariff Number | 85015230 |
| Dimension Diagram | 609959-001 |
| Drive End Flange Type | Standard |
| Enclosure Type | DP |
| ETIM 7 | EC001851 - Electric motor |
| Field Current | 3.11 A A |
| Field Voltage | 300 V V |
| Frame Material | Explosed Laminations |
| Frame Size | Undefined |
| Global Commercial Alias | D5150R-BV |
| Gross Volume | 40455 in³ |
| Gross Weight | 753.999 lb |
| Horsepower Rating UL/CSA | 50.000 Hp |
| Insulation Class | F |
| Invoice Description | 50HP,1150RPM,DC,2514ATZ,DPG-FV, |
| Made To Order | No |
| Maximum Speed | 1900 r/min |
| Medium Description | DP Enclosure, (D5150R-BV) |
| Minimum Order Quantity | 1 piece |
| Motor Base Type | Rigid |
| Motor Frame Size | C2514ATZ |
| Mounting Orientation | Horizontal |
| Order Multiple | 1 piece |
| Output Power | 50 Hp |
| Product Name | DC Integral HP RPMIII Wound Field |
| Product Net Depth / Length | 46.5 in |
| Product Net Height | 29 in |
| Product Net Weight | 753.999 lb |
| Product Net Width | 30 in |
| Product Type | Undefined |
| Quote Only | No |
| Rated Speed | 1150 r/min |
| Selling Unit of Measure | piece |
| Service Factor | 1.00 |
| Service Factor Percentage | 1.00 % |
| Shaft Diameter | 2.37 in |
| Short Description | DP, |
| Standards | NEMA |
| Stocked At (Warehouses) | China, Fort Smith, Arkansas, United States, Alaska, United States |
| Type of Duty | Continuous |
| Voltage Code | 500 Va, 300 Vf |
