PM5072-MC-KIT-EC

Name: PM5072-MC-KIT-EC
Brand: ABB
SKU: 1SAP125000R0173

MPN: 1SAP125000R0173 · Brand: ABB

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	AC500-eCo CPUs
Lifecycle	active
Warranty	12-month (new) · 3-month (used/refurbished)
Weight	0.36 kg

Shipping & availability

When can 1SAP125000R0173 be shipped?

1SAP125000R0173 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 1SAP125000R0173 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 1SAP125000R0173 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 1SAP125000R0173, subject to availability and destination.

PM5072-MC-KIT-EC:AC500,Mach.Control. Kit PM5072-T-2ETH+MC+ ETHCAT Runtime license,spring term.,Pack. Unit: 1 piece

Specifications

Ordering

CN8	85371091
Invoice Description	AC500 Machine Control Kit PM5072-T-2ETH+MC+ETHCAT Runtime license, spring term., Pack. Unit: 1 piece (PM5072-MC-KIT-EC)
Made To Order	No
Minimum Order Quantity	1 piece
Order Multiple	1 piece
Selling Unit of Measure	piece

Dimensions

Product Net Weight	0.363 kg kg
Product Net Depth / Length	250 mm mm
Product Net Height	110 mm mm
Product Net Width	180 mm mm
Gross Weight	0.73 kg kg
Package Level 1 Depth / Length	260 mm mm
Package Level 1 Height	120 mm mm
Package Level 1 Width	180 mm mm
Package Level 1 Units	1 carton

Certificates and Declarations

Declaration of Conformity - CE	3ADR980147
REACH Date	20241206
REACH Declaration	3ADR980139
REACH Information	True - contains substances > 0.1 mass percentage
RoHS Declaration	3ADR980147
RoHS Information	Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019

Technical

Function	Contains PM5072-2ETH, TA5212-TSPF, PS5611-MC-EC-e
Memory Size	9100 kB
Memory Type User Data	RAM
Controller Processing Time	0.00002 ms
Number of Digital Inputs	12
Number of Digital Outputs	8
Number of Digital Configurable I/Os	2
Input Voltage Type	DC
Rated Voltage (Ur)	24 V DC V
Supply Voltage	20.4 ... 28.8 V DC V
