Accessories for relay modules; Operation status indicator: red; Nominal operating voltage: 24 VDC
MPN: 788-120 · Brand: Wago
Price on request
Request a Quote
12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
Quick facts
| Availability | Confirmed on request |
| Category | Relay and Optocoupler Modules |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can 788-120 be shipped?
788-120 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 788-120 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 788-120 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 788-120, subject to availability and destination.
Accessories for relay modules; Operation status indicator: red; Nominal operating voltage: 24 VDC 788-120
Specifications
Notes
| Note | Only required when using relays without integrated status indicator! |
Technical data - Operating data
| Nominal operating voltage | 24 VDC |
| Operating voltage | 12 … 24 VDC |
| Current consumption at U<sub>N</sub> | 2.4 mA |
Technical data - Signaling
| Status indicator | Red LED |
Safety and protection
| Protection type | IP20 |
Mechanical data
| Mounting type | Pluggable module |
Material data
| Note (material data) | Information on material specifications can be found here |
| Fire load | 0.037 MJ |
| Weight | 1.5 g |
Environmental requirements
| Ambient temperature (operation at U<sub>N</sub>) | -40 … +70 °C |
| Ambient temperature UL (operation at U<sub>N</sub>) | -40 … +50 °C |
| Ambient temperature (storage) | -40 … +70 °C |
| Processing temperature | -25 … +50 °C |
Commercial data
| Product Group | 6 (INTERFACE ELECTRONIC) |
| PU (SPU) | 50 (25) pcs |
| Packaging type | box |
| Country of origin | DE |
| GTIN | 4045454351960 |
| Customs tariff number | 85318070000 |
Product Classification
| UNSPSC | 39121544 |
| eCl@ss 10.0 | 27-37-16-92 |
| eCl@ss 9.0 | 27-37-16-92 |
| ETIM 9.0 | EC002586 |
| ETIM 10.0 | EC002586 |
| ECCN | NO US CLASSIFICATION |
Environmental Product Compliance
| CAS-No. | 7439-92-1, 79-94-7 |
| REACH Candidate List Substance | 2,2',6,6'-tetrabromo-4,4'-isopropylidenediphenol, Lead |
| RoHS Compliance Status | Compliant,With Exemption |
| RoHS Exemption | 7(a) |
| SCIP notification number (Austria) | 1440007f-f0d4-476a-a43f-846f38699300 |
| SCIP notification number (Belgium) | c88d50f8-7dd4-43b9-b1fe-b9a921b052da |
| SCIP notification number (Bulgaria) | d55f525f-261e-4715-8d07-f634781e3dfc |
| SCIP notification number (Czech Republic) | f9af606f-092b-4c4d-b983-52b8f43a02bb |
| SCIP notification number (Denmark) | a756e293-6456-4398-b8da-a230225e464c |
| SCIP notification number (Finland) | 7944b8ba-f47b-4761-aa83-a01185d00af6 |
| SCIP notification number (France) | bb166adb-0e66-4bb5-aa29-5ac0767a0b24 |
| SCIP notification number (Germany) | 17857ce1-2886-4b8a-8cc7-b10a159072e5 |
| SCIP notification number (Hungary) | 2122141f-80e0-4070-a6b8-5005603992eb |
| SCIP notification number (Italy) | 7982b0fd-51a0-453e-a6f7-dfe8c146cc38 |
| SCIP notification number (Netherlands) | 25181f59-1427-4951-ad22-1bb566ada3dd |
| SCIP notification number (Poland) | 2f2e9239-c5f4-48e3-a239-95ca75f52fd9 |
| SCIP notification number (Romania) | e4b3e5ec-647f-44b4-9bad-46bcd8339583 |
| SCIP notification number (Sweden) | 735e05a7-7c1c-4331-bd98-94a11157904a |
