Sick LL3-TS40
Quick facts
| Availability | Confirmed on request |
| Category | Fiber-optic cables |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can LL3-TS40 be shipped?
LL3-TS40 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up LL3-TS40 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for LL3-TS40 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for LL3-TS40, subject to availability and destination.
Fiber-optic sensors | Fiber-optic cables | LL3-TS40 | Functional principle: Through-beam system | Fiber-optic head design: Flat type, 90° deflection, Array | Fiber length: 2,000 mm | Fiber-optic head array width: 40 mm | Fiber material: Plastic | Jacket material: Plastic | Fiber head material: Plastic | Included with delivery: Mounting, 4 x M3 Phillips-head screw, FC fiber cutter (5304141), protective cladding for fiber head
Specifications
Features
| Device type | Fiber-optic cables |
| Functional principle | Through-beam system, consisting of a sender and a receiver |
| Fiber-optic head design | Flat type, 90° deflection, Array |
| Application | High flexible (static), Area detection |
| Special features | Long fiber optic cable cell |
| Compatible fiber-optic amplifiers | GLL70, WLL80, WLL180, GLL170(T), WLL24 Ex |
| Sensing range max. | 3,600Â mm (Sensing range of WLL80 at 8Â ms) |
| Minimal object diameter | 0.4 mm 1) |
| Angle of dispersion | 25° |
| Integrated lens | Yes |
| Compatibility tip adapters | No |
| Compatibility with infrared light | No |
| Optical fiber cable can be shortened | â |
| Adapter end sleeves required | No |
| Included with delivery | Mounting, 4 x M3 Phillips-head screw, FC fiber cutter (5304141), protective cladding for fiber head |
Mechanics
| Light emission | Radial |
| Fiber-optic head array width | 40Â mm |
| Fiber length | 2,000 mm |
| Bending radius | 2Â mm |
| Dynamic flexibility (robotics) | No |
| Outside diameter, optical fiber cable connection | 2.2Â mm |
| Fiber arrangement | Multi-fiber |
| Core structure | Ã 1,0Â mm Multi-fiber |
| Optical fiber head | Polyamid (PA) |
| Sheath | Polyethylen (PE) |
| Fibers | Polymethylmethacrylat (PMMA) |
| Weight | 44Â g |
Ambient data
| Ambient operating temperature | â40 °C ... +60 °C |
Sensing ranges with GLL70
| Operating mode 50 µs | 3,600 mm |
| Operating mode 250 µs | 3,600 mm |
| Operating mode 1Â ms | 3,600Â mm |
| Operating mode 4Â ms | 3,600Â mm |
Sensing ranges with WLL80
| Operating mode 16 µs | 3,600 mm |
| Operating mode 70 µs | 3,600 mm |
| Operating mode 250 µs | 3,600 mm |
| Operating mode 500 µs | 3,600 mm |
| Operating mode 1Â ms | 3,600Â mm |
| Operating mode 2Â ms | 3,600Â mm |
| Operating mode 8Â ms | 3,600Â mm |
| Note | Sensing ranges related to fiber-optic sensors with type of light: visible red light |
Sensing ranges with WLL180T
| Operating mode 16 µs | 3,000 mm |
| Operating mode 70 µs | 4,000 mm |
| Operating mode 250 µs | 4,000 mm |
| Operating mode 2Â ms | 4,000Â mm |
| Operating mode 8Â ms | 4,000Â mm |
| Note | Sensing ranges related to fiber-optic sensors with type of light: visible red light |
Sensing ranges with GLL170
| Operating mode 250 µs | 3,500 mm |
Sensing ranges with GLL170T
| Operating mode 50 µs | 3,500 mm |
| Operating mode 250 µs | 3,500 mm |
Classifications
| ECLASS 5.0 | 27270905 |
| ECLASS 5.1.4 | 27270905 |
| ECLASS 6.0 | 27270905 |
| ECLASS 6.2 | 27270905 |
| ECLASS 7.0 | 27270905 |
| ECLASS 8.0 | 27270905 |
| ECLASS 8.1 | 27270905 |
| ECLASS 9.0 | 27270905 |
| ECLASS 10.0 | 27270905 |
| ECLASS 11.0 | 27270905 |
| ECLASS 12.0 | 27270905 |
| ETIM 5.0 | EC002651 |
| ETIM 6.0 | EC002651 |
| ETIM 7.0 | EC002651 |
| ETIM 8.0 | EC002651 |
| UNSPSC 16.0901 | 39121528 |
