Home / ABB / M2QA 355MLD 2
Available on request

M2QA 355MLD 2

MPN: 3GQP351440-ADG · Brand: ABB
Price on request
12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

Quick facts

AvailabilityConfirmed on request
CategoryFlameproof IEC Low voltage motors
Lifecycleactive
Warranty12-month (new) · 3-month (used/refurbished)
Weight1726.6 kg

Shipping & availability

When can 3GQP351440-ADG be shipped?

3GQP351440-ADG is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 3GQP351440-ADG in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 3GQP351440-ADG and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 3GQP351440-ADG, subject to availability and destination.

(3GQP351440-ADG)

Specifications

Ordering

ABB Type DesignationM2QA 355MLD 2
Invoice DescriptionM2QAP 355MLD 2
Product Name3-Phase squirrel cage motor
Product TypeCQP2__M2QP_IE2_CI
Country or Territory of OriginChina
Customs Tariff Number85015381
Stocked At (Warehouses)Shanghai, China
Medium Description?kW, 2P, Frame Size 355, 3 Phases, 400V, ?Hz, IP55 Enclosure, IMB3/IM1001 Mounting (3GQP351440-ADG) kW
Short Description?kW, 2P, Frame Size 355, 3PH, 400V, ?Hz, IP55, IMB3/IM1001 kW

Electrical

Temperature Class Default--
Altitude1000 m m
Ambient Temperature40 °C
IC ClassIC411
IE Class Data (50 Hz)IE Class IE2, Full Load (100%) 95.0 %, Partial Load (75%) 95.3 %, Partial Load (50%) 95.0 %
IP ClassIP55
Insulation ClassICLF
Direction of RotationBoth sides
Number of Poles (High)2
Two Speed MotorNo
Type of DutyS1
Voltage CodeD

Mechanical

Frame MaterialCast Iron
Frame Size355
Bearing6319M/C4
Bearing NDE6319M/C4
IM ClassIMB3 IM1001
Terminator Box LocationD-End top

Dimensions

Product Net Weight1726.6 kg kg
Gross Weight1756.6 kg kg

Environmental

WEEE Category4. Large Equipment (Any External Dimension More Than 50 cm) cm

External Classifications and Standards

UNSPSC26101100
