M2BAF 80MA 4

MPN: 3GBA082310-ASJCN · Brand: ABB
Price on request
12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

Quick facts

AvailabilityConfirmed on request
CategoryFlameproof IEC Low voltage motors
Lifecycleactive
Warranty12-month (new) · 3-month (used/refurbished)
Weight15 kg

Shipping & availability

When can 3GBA082310-ASJCN be shipped?

3GBA082310-ASJCN is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 3GBA082310-ASJCN in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 3GBA082310-ASJCN and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 3GBA082310-ASJCN, subject to availability and destination.

(3GBA082310-ASJCN)

Specifications

Ordering

ABB Type DesignationM2BAF 80MA 4
Invoice DescriptionM2BAF 80MA 4
Product Name3-Phase squirrel cage motor
Product TypeCBF2__M2BAF_IE2_CI
Country or Territory of OriginChina
Customs Tariff Number85015100
Stocked At (Warehouses)Shanghai, China, Guangzhou, China, China
Medium Description?kW, 4P, Frame Size 80, 3 Phases, 400V, ?Hz, IP55 Enclosure, IMB3/IM1001 Mounting (3GBA082310-ASJCN) kW
Short Description?kW, 4P, Frame Size 80, 3PH, 400V, ?Hz, IP55, IMB3/IM1001 kW

Electrical

Temperature Class Default--
Altitude1000 m m
Ambient Temperature40 °C
IC ClassIC411
IE Class Data (50 Hz)IE Class IE2, Full Load (100%) 77.1 %, Partial Load (75%) 76.6 %, Partial Load (50%) 74.0 %
IP ClassIP55
Insulation ClassICLF
Direction of RotationBoth sides
Number of Poles (High)4
Two Speed MotorNo
Type of DutyS1
Voltage CodeS

Mechanical

Frame MaterialCast Iron
Frame Size80
Bearing6204-2Z/C3
Bearing NDE6204-2Z/C3
IM ClassIMB3 IM1001
Terminator Box LocationD-End top

Dimensions

Product Net Weight15 kg kg
Gross Weight16 kg kg

External Classifications and Standards

UNSPSC26101100
