Home / ABB / M2BAF 160MLC 2
Available on request

M2BAF 160MLC 2

MPN: 3GBA161430-ADPCN · Brand: ABB
Price on request
12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

Quick facts

AvailabilityConfirmed on request
CategoryFlameproof IEC Low voltage motors
Lifecycleactive
Warranty12-month (new) · 3-month (used/refurbished)
Weight162 kg

Shipping & availability

When can 3GBA161430-ADPCN be shipped?

3GBA161430-ADPCN is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 3GBA161430-ADPCN in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 3GBA161430-ADPCN and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 3GBA161430-ADPCN, subject to availability and destination.

M2BAF 160MLC 2

Specifications

Ordering

ABB Type DesignationM2BAF 160MLC 2
Invoice DescriptionM2BAF 160MLC 2
Product Name3-Phase squirrel cage motor
Product TypeCBF4__M2BAF_IE4_CI
Country or Territory of OriginChina
Customs Tariff Number85015230
Medium Description?kW, 2P, Frame Size 160, 3 Phases, 400V, ?Hz, IP55 Enclosure, IMB3/IM1001 Mounting (3GBA161430-ADPCN) kW
Short Description?kW, 2P, Frame Size 160, 3PH, 400V, ?Hz, IP55, IMB3/IM1001 kW

Electrical

Temperature Class Default--
Altitude1000 m m
Ambient Temperature40 °C
IC ClassIC411
IE Class Data (50 Hz)IE Class IE4, Full Load (100%) 93.7 %, Partial Load (75%) 94.3 %, Partial Load (50%) 94.3 %
IP ClassIP55
Insulation ClassICLF
Direction of RotationBoth sides
Number of Poles (High)2
Two Speed MotorNo
Type of DutyS1
Voltage CodeD

Mechanical

Frame MaterialCast Iron
Frame Size160
Bearing6309-2Z/C3
Bearing NDE6209-2Z/C3
IM ClassIMB3 IM1001
Terminator Box LocationD-End top

Dimensions

Product Net Weight162 kg kg
Gross Weight172 kg kg

External Classifications and Standards

UNSPSC26101100
12-month warrantyon all new stock
3-month warrantyon used & refurbished parts
30-day returnsno restocking fee on unused parts
Global shippingFast, tracked delivery worldwide
