M3LP 355MLD 4
MPN: 3GLP352440-BDK · Brand: ABB
Price on request
12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
Quick facts
| Availability | Confirmed on request |
| Category | Flameproof IEC Low voltage motors |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
| Weight | 1900 kg |
Shipping & availability
When can 3GLP352440-BDK be shipped?
3GLP352440-BDK is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 3GLP352440-BDK in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 3GLP352440-BDK and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 3GLP352440-BDK, subject to availability and destination.
M3LP 355MLD 4
Specifications
Ordering
| ABB Type Designation | M3LP 355MLD 4 |
| Invoice Description | M3LP 355MLD 4 |
| Product Name | 3-Phase squirrel cage motor |
| Product Type | 3LP3__water_cooled_motor_IE3 |
| Country or Territory of Origin | Finland |
| Customs Tariff Number | 85015394 |
| Medium Description | ?kW, 4P, Frame Size 355, 3 Phases, 400V, ?Hz, IP55 Enclosure, IMB5/IM3001 Mounting (3GLP352440-BDK) kW |
| Short Description | ?kW, 4P, Frame Size 355, 3PH, 400V, ?Hz, IP55, IMB5/IM3001 kW |
Electrical
| Temperature Class Default | -- |
| Altitude | 1000 m m |
| Ambient Temperature | 40 °C |
| IC Class | IC71W |
| IE Class Data (50 Hz) | IE Class IE3, Full Load (100%) 96.0 %, Partial Load (75%) 96.0 %, Partial Load (50%) 95.6 % |
| IP Class | IP55 |
| Insulation Class | ICLF |
| Direction of Rotation | Both sides |
| Number of Poles (High) | 4 |
| Two Speed Motor | No |
| Type of Duty | S1 |
| Voltage Code | D |
Mechanical
| Frame Material | Welded Steel |
| Frame Size | 355 |
| Bearing | 6322/C3 |
| Bearing NDE | 6316/C3 |
| IM Class | IMB5 IM3001 |
| Terminator Box Location | Top |
Dimensions
| Product Net Weight | 1900 kg kg |
| Gross Weight | 1930 kg kg |
Environmental
| WEEE Category | 4. Large Equipment (Any External Dimension More Than 50 cm) cm |
External Classifications and Standards
| UNSPSC | 26101100 |
