Home / ABB / M3GP 100LA 8
Available on request

M3GP 100LA 8

MPN: 3GGP104101-BDB · Brand: ABB
Price on request
12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

Quick facts

AvailabilityConfirmed on request
CategoryFlameproof IEC Low voltage motors
Lifecycleactive
Warranty12-month (new) · 3-month (used/refurbished)
Weight30 kg

Shipping & availability

When can 3GGP104101-BDB be shipped?

3GGP104101-BDB is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 3GGP104101-BDB in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 3GGP104101-BDB and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 3GGP104101-BDB, subject to availability and destination.

M3GP 100LA 8

Specifications

Ordering

ABB Type DesignationM3GP 100LA 8
Invoice DescriptionM3GP 100LA 8
Product Name3-Phase squirrel cage motor
Product Type3GP0__M3GP_CI
Country or Territory of OriginFinland
Customs Tariff Number85015220
Medium Description?kW, 8P, Frame Size 100, 3 Phases, 400V, ?Hz, IP55 Enclosure, IMB5/IM3001 Mounting (3GGP104101-BDB) kW
Short Description?kW, 8P, Frame Size 100, 3PH, 400V, ?Hz, IP55, IMB5/IM3001 kW

Electrical

Temperature Class DefaultT3
Altitude1000 m m
Ambient Temperature40 °C
IC ClassIC411
IE Class Data (50 Hz)IE Class IE2, Full Load (100%) 66.2 %, Partial Load (75%) 64.7 %, Partial Load (50%) 58.2 %
IE Class Data (60 Hz)IE Class IE2, Full Load (100%) 66.0 %, Partial Load (75%) 64.1 %, Partial Load (50%) 56.7 %
IP ClassIP55
Insulation ClassICLF
Direction of RotationBoth sides
Number of Poles (High)8
Two Speed MotorNo
Type of DutyS1
Voltage CodeD
EX-ProtectionExec
Gas GroupIIC

Mechanical

Frame MaterialCast Iron
Frame Size100
Bearing6206-2Z/C3
Bearing NDE6205-2Z/C3
LubricationFor life
IM ClassIMB5 IM3001
Terminator Box LocationTop

Dimensions

Product Net Weight30 kg kg
Gross Weight35 kg kg

Environmental

WEEE Category5. Small Equipment (No External Dimension More Than 50 cm) cm

External Classifications and Standards

StandardsIEC 60034-1
UNSPSC26101100
